david cranmer of nervous squirrel reveals the duck machine david cranmer of nervous squirrel reveals the duck machine
oct 23, 2013

david cranmer of nervous squirrel reveals the duck machine

david cranmer of nervous squirrel reveals the duck machine
all images courtesy of the nervous squirrel







moving in a graceful pattern this mechanical sculpture by british designer david cranmer of nervous squirrel consists of 49 independently controlled rubber ducks. the piece was commissioned by specialist motor manufacturing company faz elektrik for a tradeshow to reveal a new range of actuators. the programmable matrix has 49 miniature motors that are controlled by 14 driver boards and 3 arduino microprocessors. the mechanisms are constructed from polycarbonate and connected to the small plastic ducks via flexible fiberglass rods. in order to join the dissimilar metals, brass guiding tubes were silver soldered to the steel frame.






‘duck machine – mechanical sculpture by dave cranmer’
video courtesy of the nervous squirrel






the little rubber ducks move up and down in a graceful patterned motion






the moving sculpture is created by independently controlled motors






side profile of the duck machine






the miniature ducks suspended in the air






detail of the ducks






detail of the machine’s polycarbonate cams






the rows of polycarbonate cams






the inside showing the mechanical construction





designboom has received this project from our ‘DIY submissions‘ feature, where we welcome our readers to submit their own work for publication. see more project submissions from our readers here.
