TU delft arch-students developed sustainable euro-pallet pavilion

TU delft arch-students developed sustainable euro-pallet pavilion
apr 06, 2015

TU delft arch-students developed sustainable euro-pallet pavilion

TU delft arch-students developed sustainable euro-pallet pavilion
all images courtesy of murtada alkaabi







wooden pallets are considerably one of the most accessible products in the world. they are used and produced by the hundreds of thousands, after which they are either recycled, repurposed, or disposed of. murtada alkaabi, alkistis kartsiou, evgenia kanli, and jingxiang liu–architecture students at TU delftsaw the material as a perfect low-cost, sustainable option for producing semi-permanent structures

TU delft arch-students developed sustainable euro-pallet pavilion
3D interior section







the ‘euro-pallet pavilion’ transforms the common euro-pallet into a means of creation for unique multi-purpose buildings. wooden triangular connections–precisely cut with CNC technology–are fabricated and connected as puzzle pieces for a fully supported form. their shape ensures efficient weight distribution and also fits perfectly in pre-existing pallet gaps. a second group of elements are adjoined to the triangles to prevent movement and horizontal displacement at connection points. the components are 12-15mm diameter wooden cylinders which can easily be hammered into place. the design can be built with only a hammer or mallet, not needing metal fasteners or adhesives of any sort. ‘euro-pallet pavilion’ can be sized as needed by adding or removing arches–each provides 3.60m2 of space.

TU delft arch-students developed sustainable euro-pallet pavilion
interior render







assembling and disassembling is non-harmful to the environment nor materials, so the structure can be continually built and rebuilt in different places. depending on the way arches are arranged, alternative formations can be made. other uses could be: art installations, art festival and event facilities, or temporary low-cost housing. fairly simple assembly, high-surplus building materials, and low-production cost make the ‘euro-pallet pavilion’ a plausible and creative resolution for nonpermanent architecture

TU delft arch-students developed sustainable euro-pallet pavilion
sunset beach render

europalletdesignboom04
building process, 1:1 scale model

europalletdesignboom05
final 1:1 scale model

TU delft arch-students developed sustainable euro-pallet pavilion
tools and elements

TU delft arch-students developed sustainable euro-pallet pavilion
alternative arrangement: spider pavilion

europalletdesignboom06
assembling method

europalletdesignboom03
structural analysis with TNO diana

europalletdesignboom02

pavilion connections: detail

europalletdesignboom01

pavilion technical connections







designboom has received this project through its ‘DIY submissions’ feature, which welcomes readers to submit their own work for publication. see more designboom readers submissions here.
