ori levin: adhoc folding canoe

‘adhoc folding canoe’ by ori levin

israeli designer ori levin from studio tsor design has created ‘adhoc’: this full-size canoe can be folded into a bag the size of a standard backpack (13 x 23 x 70 centimeters). weighing 4.1 kilograms, the materials were carefully selected to be both lightweight and resilient: the frame is made of carbon fiber while the hull is made of aramid, a heat-resistant synthetic fabric used in racing sails.

a corner lock holds the telescopic poles to form each end, and a parasol-like mechanism in the center maintains the structure of the sides. the canoe can be assembled in approximately five minutes.

rear overhead view

corner lock

central folding mechanism

concept render

assembly

feasibility study, first trial

feasibility study, second trial

designboom has received this project from our ‘DIY submissions’ feature, where we welcome our readers to submit their own work for publication.
